55 FT-M1211A
4M05975 TEMPLATE
ID Refer ence Qty Descr i ption
2 2D01821 1 Axle D25/L1394
3 2S04646 1 Left ski guide
4 2S04647 1 Right ski guide
5 2S04694 1 Left ski
6 2S04696 1 Right ski
7 10-0358 4 Ball-bearing bushing Øi25/Øe35/L40
8 2T07601 1 Arm support bracket V2
9 2T06801 1 GIO bracket
10 10-0200 2 Flange Ø20/2 holes
11 2S04645 1 Moving arm
12 10-0208 4 Clevis ball joint M10
13 03-0620 0385 1 Galvanized threaded rod M10 L0385
14 03-0620 0675 1 Galvanized threaded rod M10 L0675
15 11-0153 2 Hex bolt CHC M10-25
16 18-0024 1 Electric strut cylinder
17 2D01830 1 Boss D20/W48/D9
18 10-0224 1 Swivel M10
NR 15-0184 1 Impulse generator
NR 15-0570 2 Captor
