Giga-tronics 8502A - A00 Pcb Assy Pre-Wave, Analog

20741-A00 PCB ASSY PRE-WAVE, ANALOG, Rev: M
Item Part Number Qty Cage Mfr’s Part Number Description
1 20740 1 58900 20740 PC BOARD, ANALOG
2 20742 REF 58900 20742 SCHEMATIC, ANALOG
3 JSP2-10024 1 09769 2-641932-1 24 PIN DIP SOCKET
4 JSP0-10008 12 09769 2-640463-1 8 PIN DIP SOCKET
5 JSP0-10014 10 09769 2-641609-1 14 PIN DIP SOCKET
6 JSP0-10016 6 09769 2-614610-2 16 PIN DIP SOCKET
7 JSP0-10028 1 09769 2-641615-1 28 PIN DIP SOCKET
8 JSP0-10040 1 09769 2-641616-1 40 PIN DIP SOCKET
C1 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM
C2 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C3 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C4 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C5 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C6 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C7 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C8 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C81 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
C9 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C10 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM
C11 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C12 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM
C13 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C14 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM
C15 CC50-B4470 1 04222 SR305C474KAA .47 UF CERAMIC X7R
C16 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C17 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C18 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C19 CC50-02100 1 04222 SR155C122MAT .001 UF CERAMIC Y5P
C20 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C21 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C22 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C24 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C25 CC50-02100 1 04222 SR155C122MAT .001 UF CERAMIC Y5P
C26 CC50-02100 1 04222 SR155C122MAT .001 UF CERAMIC Y5P
C27 CC50-02100 1 04222 SR155C122MAT .001 UF CERAMIC Y5P
C28 CC98-00470 1 ——- CCD470 47 PF 1KV CERAMIC NPO
C29 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C30 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C31 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C32 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C33 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C34 CC50-02100 1 04222 SR155C122MAT .001 UF CERAMIC Y5P
C35 CC99-02470 1 56289 5GA-D47 4700 PF 1000V CERAMIC
C36 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C37 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C38 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C39 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C40 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C41 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C42 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C43 CC98-00470 1 ——- CCD470 47 PF 1KV CERAMIC NPO
C44 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C45 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C46 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C47 CD99-01470 1 ——- CM06FD471F03 470 PF DIP MICA
C48 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C49 CC50-02100 1 04222 SR155C122MAT .001 UF CERAMIC Y5P
C51 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM
C52 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM
C53 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM
C54 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
C55 CC98-00470 1 ——- CCD470 47 PF 1KV CERAMIC NPO
C56 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R
Parts Lists
Manual No. 20790, Rev C, November 1998
7-25
