Giga-tronics 8502A - 20513-A00 8502 A Chassis Assy; 21147 Front Sub Panel Assy 8502 A; 21148 Rear Panel Assy 8502 A

20513-A00 8502A CHASSIS ASSY, Rev: N
Item Part Number Qty Cage Mfr’s Part Number Description
1 10129 1 58900 10129 LABEL, CODE AND SERIAL NUMBER
2 12701-004 2 58900 12701-004 GUIDE, 4.90"
3 12701-012 1 58900 12701-012 GUIDE, 1.00"
4 SPA0-00012 1 31918 FSC-BLACK BLACK BUTTON
5 14913 1 58900 14913 LABEL, H.V. SHIELD
6 HGP0-03000 13 32559 E-300 3" CARD GUIDE
7 16869 2 58900 16869 DELAY LINE ASSEMBLY
8 16949 1 58900 16949 LEFT CABINET SIDE
9 16950 1 58900 16950 RIGHT CABINET SIDE
10 16951 1 58900 16951 FRONT FRAME 8500
11 16952 1 58900 16952 REAR FRAME 8500
12 16953 1 58900 16953 BASE PLATE
13 16954 1 58900 16954 LEFT PCB MTG BRACKET
14 16955 1 58900 16955 RIGHT PCB MOUNTING BKT
15 16964 1 58900 16964 AC SWITCH SHAFT
16 16999 1 58900 16999 AC SWITCH COVER
17 17012 1 58900 17012 POWER SUPPLY ENCLOSURE
18 17217 5 58900 17217 RF SHIELD
19 17218 10 58900 17218 INSULATOR, RF SHIELD
20 17311 1 58900 17311 SUPPORT BRACKET, PCB
21 20196 REF 58900 20196 SCHEMATIC, FRONT PNL INTERFACE
22 20522 REF 58900 20522 SCHEMATIC 8501A & 8502A INSTR
23 20527 REF 58900 20527 SCHEMATIC, FRONT PANEL
24 XARC-00002 0 58900 XARC-00002 SILVER-FILLED RTV
25 21118 1 58900 21118 LABEL, TESTED BY
26 70113 REF 58900 70113 PROCEDURE, MODEL 8502A
31 60334 REF 58900 60334 8500A CALIBRATION PROC
27 60304 REF 58900 60304 8500A PRETEST PROC
29 60348 REF 58900 60348 MODEL 850X/850XA SYS TEST PRO
30 30019 REF 58900 30019 8500 & 8500A JIT FLOW CHART
A1 16932-001 1 58900 16932-001 INTERCONNECT PCB ASSY
A2 16995 1 58900 16995 PCB ASSY, POWER SUPPLY
A3 21014 1 58900 21014 PCB ASSY GPIB/CAL CONTROL 8500
A4 16878 1 58900 16878 PCB ASSY., CPU
A5 16685 1 58900 16685 P.C. BRD. ASSY., DIGITAL DELAY
A6 20741 1 58900 20741 ANALOG PCB ASSY
A7 20741 1 58900 20741 ANALOG PCB ASSY
A8 20195 1 58900 20195 PCB ASSY, FR PNL INTERFACE
A12 20055-001 1 58900 20055-001 ASSY, 1GHZ CALIBRATOR TYPE N
A13 21147 1 58900 21147 FRONT SUB PANEL ASSY 8502A
A14 21148 1 58900 21148 REAR PANEL ASSY 8502A
CR1 DBMC-00980 1 58900 DBMC-00980 MDA980-2 BRIDGE RECT
LS1 ISS0-00001 1 58900 ISS0-00001 2" 8 OHM SPEAKER
W7 17056 1 58900 17056 SPEAKER CABLE ASSY
W9 17091-001 1 58900 17091-001 W9 W-R DISC CABLE ASSY
W10 17163-001 1 58900 17163-001 W-PR DISC CABLE ASSY
Series 8500A Peak Power Meters
7-4
Manual No. 20790, Rev C, November 1998
