21145 FRONT SUB PANEL ASSY 8501A, Rev: A
Item Part Number Qty Cage Mfr’s Part Number Description
1 ETIM-02062 1 2R182 862 2 LUG TERMINAL STRIP
2 HSTH-41104 12 06540 8217-46-B-0440-28 4-40 X 23/32 HEX SPACER
3 14955-065 1 58900 14955-065 LABEL “TO A1J16"
4 20509 1 58900 20509 FRONT SUB PANEL, 8501A
5 20736 2 58900 20736 GUARD, FLAT CABLE
6 20879 1 58900 20879 EL DISPLAY MODULE ASSEMBLY
7 21039 1 58900 21039 BRKT, STRAIN RELIEF
A9 20526-001 1 58900 20526-001 PC BOARD ASSY, FRONT PANEL
B2 21100 1 58900 21100 ROTARY ENCODER ASSY
C1 11573-001 1 3W023 CW15C102K CAP MIN CER .001MF 20% 50VDC
W1 17051 1 58900 17051 DETECTOR INPUT CABLE ASSY
W4 20570 1 58900 20570 CABLE ASSY, FR PANEL-INTCON
W8 20721 1 ——- 20721 CABLE ASSY, EL DSPL-FP INTFC
21147 FRONT SUB PANEL ASSY 8502A, Rev: A
Item Part Number Qty Cage Mfr’s Part Number Description
1 ETIM-02062 1 2R182 862 2 LUG TERMINAL STRIP
2 ETIM-02063 1 2R182 820 2 LUG TERMINAL STRIP
3 HSTH-41104 12 06540 8217-46-B-0440-28 4-40 X 23/32 HEX SPACER
4 14955-065 1 58900 14955-065 LABEL “TO A1J16"
5 14955-069 1 58900 14955-069 LABEL “TO A1J17"
6 20511 1 58900 20511 FRONT SUB PANEL 8502A
7 20736 2 58900 20736 GUARD, FLAT CABLE
8 20879 1 58900 20879 EL DISPLAY MODULE ASSEMBLY
9 21039 2 58900 21039 BRKT, STRAIN RELIEF
A9 20526-002 1 58900 20526-002 PC BOARD ASSY, FRONT PANEL
B2 21100 1 58900 21100 ROTARY ENCODER ASSY
C1 11573-001 1 3W023 CW15C102K CAP MIN CER .001MF 20% 50VDC
C2 11573-001 1 3W023 CW15C102K CAP MIN CER .001MF 20% 50VDC
W1 17051 1 58900 17051 DETECTOR INPUT CABLE ASSY
W4 20570 1 58900 20570 CABLE ASSY, FR PANEL-INTCON
W8 20721 1 ——- 20721 CABLE ASSY, EL DSPL-FP INTFC
W12 17051 1 58900 17051 DETECTOR INPUT CABLE ASSY
Parts Lists
Manual No. 20790, Rev C, November 1998
7-5
