21146 REAR PANEL ASSY 8501A, Rev: A
Item Part Number Qty Cage Mfr’s Part Number Description
1 17141 1 58900 17141 REAR PANEL
2 HPM0-00687 2 57771 D3047 11/16 HOLE PLUG
3 HPM0-00500 1 18310 790-3008 1/2 HOLE PLUG
4 JIB0-01089 5 56501 RA-250 FEMALE QUICK DISCONNECT
5 16966 1 58900 16966 AC SWITCH MTG BKT
6 16973 4 58900 16973 INSULATING FLAT WASHER
7 BHF0-13000 1 9Y422 FF325G 3" FAN FILTER
8 17161 1 31918 51985 PLUNGER, EXTENDER
9 19976 1 58900 19976 COVER PLATE, 8500 CALIBRATOR
10 JLFL-01503 1 05245 JA413 2A 120V LABEL
11 HPM0-00375 3 2R182 652 3/8 HOLE PLUG
F1 FSAC-00200 1 ——- MDL-2 2A SB FUSE 3AG
J1 JLFF-06250 1 05245 6J4 LINE FILTER/CONNEC
J2 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
J3 JRDF-00005 1 58900 JRDF-00005 BNC F PANEL MOUNT
J4 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
J6 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
J7 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
R2 RABA-01001 1 01121 WA1NO24S101MZ 100 OHM POT PANEL MOUNT
S1 13260 1 2W053 001399 SWITCH PUSHBUTTON POWER
T1 16762 1 58900 16762 TRANSFORMER PWR
W2 17280 1 58900 17280 FAN ASSY
W3 17131 1 58900 17131 REAR PANEL CABLE ASSY 8502
W11 17259-001 1 58900 17259-001 BNC TO SMC RG178B/U CABLE ASSY
21148 REAR PANEL ASSY 8502A, Rev: A
Item Part Number Qty Cage Mfr’s Part Number Description
1 HPM0-00687 2 57771 D3047 11/16 HOLE PLUG
2 HPM0-00500 1 18310 790-3008 1/2 HOLE PLUG
3 JIB0-01089 5 56501 RA-250 FEMALE QUICK DISCONNECT
4 16966 1 58900 16966 AC SWITCH MTG BKT
5 16973 4 58900 16973 INSULATING FLAT WASHER
6 BHF0-13000 1 9Y422 FF325G 3" FAN FILTER
7 17141 1 58900 17141 REAR PANEL
8 17161 1 31918 51985 PLUNGER, EXTENDER
9 19976 1 58900 19976 COVER PLATE, 8500 CALIBRATOR
10 JLFL-01503 1 05245 JA413 2A 120V LABEL
11 HPM0-00375 1 2R182 652 3/8 HOLE PLUG
F1 FSAC-00200 1 ——- MDL-2 2A SB FUSE 3AG
J1 JLFF-06250 1 05245 6J4 LINE FILTER/CONNEC
J2 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
J3 JRDF-00005 1 58900 JRDF-00005 BNC F PANEL MOUNT
J4 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
J6 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
J7 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
J8 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
J9 JRDF-00001 1 09769 31-221-RFX BNC F PANEL MOUNT
R2 RABA-01001 1 01121 WA1NO24S101MZ 100 OHM POT PANEL MOUNT
S1 13260 1 2W053 001399 SWITCH PUSHBUTTON POWER
T1 16762 1 58900 16762 TRANSFORMER PWR
W2 17280 1 58900 17280 FAN ASSY
W3 17131 1 58900 17131 REAR PANEL CABLE ASSY 8502
W11 17259-001 1 58900 17259-001 BNC TO SMC RG178B/U CABLE ASSY
