180 ! COMMANDS WILL INITIATE THE
190 ! PPM’S PLOT ROUTINE. THE
200 ! ADDRESS OF THE PLOTTER AND
210 ! PPM MUST BE SET CORRECTLY -
220 ! IN THIS CASE THE PPM IS AT 704,
230 ! AND THE PLOTTER IS AT 706.
240 OUTPUT 704;PLCN&C$
250 ! SEND CODE NUMBER TO PPM
260 OUTPUT 704;PLPN&P$
270 ! SEND PART NUMBER TO PPM
280
290 ! THESE ARE THE COMMANDS TO
300 ! INITIATE THE PLOT ROUTINE:
310
320 OUTPUT 704;PLOT
330 ! (PUTS PPM IN PLOT OUTPUT MODE)
340
350 SEND 7;UNL
360 SEND 7;LISTEN 6
370 ! (LISTEN ADDRESSES THE PLOTTER)
380 SEND 7;TALK 4
390 ! (TALK ADDRESSES THE PPM)
400
410 SEND 7;DATA
420 ! (RELEASES ATN LINE ALLOWING
430 ! PLOTTING TO BEGIN)
440
450 WAIT 180
460 ! WAIT UNTIL PLOTTING HAS
470 ! FINISHED BEFORE UNTALKING
480 ! THE PPM. PLOT TAKES ABOUT
490 ! 3 MINUTES
500
510 ! UNTALK AND UNLISTEN ALL BUS
520 ! DEVICES
530 SEND 7;UNT UNL
540 END
Remote Operation
Manual No. 20790, Rev C, November 1998
3-9
