Reading and Defining Pulse Parameters
The following commands read the current values set for the pulse parameters:
* PUFT Get Pulse Fall Time. The unit will respond with:
FALAddddddE-e (If channel A selected)
FALBddddddE-e (If channel B selected)
(d = seconds; e = exponent)
☛ NOTE:
*PUFT, *PURT, and *PUWD operate only in the Graph Mode.
* PURT Get Pulse Rise Time. The unit will respond with:
RISAddddddE-e (If channel A selected)
RISBddddddE-e (If channel B selected)
(d = seconds: e = exponent)
* PUWD Get Pulse Width. The unit will respond with:
WIDAddddddE-e (If channel A selected)
WIDBddddddE-e (If channel B selected)
(d = seconds: e = exponent)
The following commands set new values for the pulse parameters:
PUFSddd Set Pulse Fall Time - Start %.
Where d = % expressed in 0.1% units. Allowable range is 1 to 999 (0.1% to 99.9%)
PUFEddd Set Pulse Fall Time - End %
Where d = % expressed in 0.1 % units. Allowable range is 1 to 999 (0.1% to 99.9%)
PURSddd Set Pulse Rise Time - Start %
Where d = % expressed in 0.1% units. Allowable range is 1 to 999 (0.1% to 99.9%)
PUREddd Set Pulse Rise Time - End %
Where d = % expressed in 0.1 % units. Allowable range is 1 to 999 (0.1% to 99.9%)
PUWSddd Set Pulse Width - Start %
Where d = % expressed in 0.1 % units. Allowable range is 1 to 999 (0.1% to 99.9%)
PUWEddd Set Pulse Width - End %
Where d = % expressed in 0.1% units. Allowable range is 1 to 999 (0.1% to 99.9%)
