Hardware Installation
1-2 ProductSpecications
CPU  Support for Intel
®
Core
™
i7 processors in the LGA2011 package
(Go to GIGABYTE's website for the latest CPU support list.)
 L3 cache varies with CPU
Chipset  Intel
®
C606 Express Chipset
Memory  8 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than the size of
the physical memory installed.
 4 channel memory architecture
 Support for DDR3 2133/1866/1600/1333/1066 MHz memory modules
 Support for ECC memory modules
 Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio  Realtek ALC898 codec
 High Denition Audio
 2/4/5.1/7.1-channel
 Support for S/PDIF Out
LAN  1 x Intel GbE LAN chip (10/100/1000 Mbit) (LAN1)
 1 x Realtek GbE LAN chip (10/100/1000 Mbit) (LAN2)
Expansion Slots  2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
* For optimum performance, if only one PCI Express graphics card is to be installed, be
sure to install it in the PCIEX16_1 slot; if you are installing two PCI Express graphics
cards, it is recommended that you install them in the PCIEX16_1 and PCIEX16_2
slots.
 1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16_2 slot. When the PCIEX8 slot
is populated, the PCIEX16_2 slot will operate at up to x8 mode.
 1 x PCI Express x16 slot, running at x4 (PCIEX4)
(The PCIEX16, PCIEX8, and PCIEX4 slots conform to PCI Express 3.0 standard.)
 1 x PCI Express x1 slot
(The PCIEX1 slot conforms to PCI Express 2.0 standard.)
 1 x PCI slot
Multi-Graphics
Technology
 Support for 3-Way/2-Way AMD CrossFireX
™
/NVIDIA SLI technology
Storage Interface  Chipset:
- 2 x SATA 6Gb/s connectors (SATA3 0~1) supporting up to 2 SATA 6Gb/s
devices
- 4 x SATA 3Gb/s connectors (SATA2 2~5) supporting up to 4 SATA 3Gb/s
devices
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
* When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the
system performance of the RAID set may vary depending on the devices being
connected.
- 8 x SAS 3Gb/s connectors (SAS2 0~7) supporting up to 8 SAS 3Gb/s devices
* The SAS connectors do not support optical drives.
- Support for RAID 0, RAID 1, and RAID 10

Gigabyte GA-X79S-UP5 User's Specifications

General

Brand	Gigabyte
Model	GA-X79S-UP5 User's
Category	Motherboard
Language	English
