Chapter 5 Appendix
5-1 ConguringSATAHardDrive(s)
ToconfigureSATAharddrive(s),followthestepsbelow:
A. Install SATA hard drive(s) in your computer.
B. Configure SATA controller mode in BIOS Setup.
C. Configure a RAID array in RAID BIOS.
(Note 1)
D. Install the SATA RAID/AHCI driver and operating system.
(Note 2)
Beforeyoubegin
Please prepare:
• At least two SATA hard drives (to ensure optimal performance, it is recommended that you use two hard
drives with identical model and capacity). If you do not want to create RAID, you may prepare only one
hard drive.
• Windows 7/Vista setup disk.
• Motherboard driver disk.
RAIDLevels
(Note 1) Skip this step if you do not want to create RAID array on the SATA controller.
(Note 2) Required when the SATA controller is set to AHCI or RAID mode.
(Note 3) When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the system performance
of the RAID set may vary depending on the devices being connected.
5-1-1 ConguringIntelC606SATAControllers
A.InstallingSATAharddrive(s)inyourcomputer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available SATA
port on the motherboard. If there is more than one SATA controller on your motherboard, refer to "Chapter 1,"
"Hardware Installation," to identify the SATA controller for the SATA port. (For example, on this motherboard,
the SATA3 0/1
(Note 3)
and SATA2 2/3/4/5 ports are supported by the C606 Chipset.) Then connect the power
connector from your power supply to the hard drive.
RAID 0 RAID 1 RAID 5 RAID 10
Minimum
Number of Hard
Drives
≥2 2 ≥3 ≥4
Array Capacity Number of hard
drives * Size of the
smallest drive
Size of the smallest
drive
(Number of hard
drives -1) * Size of
the smallest drive
(Number of hard
drives/2) * Size of the
smallest drive
Fault Tolerance No Yes Yes Yes
