Step 3:

After entering the CREATEVOLUMEMENU screen, enter a volume name with 1~16 letters (letters cannot be

special characters) under the Name item and press <Enter>. Then, select a RAID level (Figure 4). RAID levels

supported include RAID 0, RAID 1, RAID 10, and RAID 5 (the selections available depend on the number of

the hard drives being installed). Press <Enter> to proceed.

Step 4:

Under Disks item, select the hard drives to be included in the RAID array. If only two hard drives are installed,

they will be automatically assigned to the array. Set the stripe block size (Figure 5) if necessary. The stripe block

size can be set from 4 KB to 128 KB. Once you have selected the stripe block size, press <Enter>.

Figure 4

Figure 5

Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 3.0.0.1184

RAID0: Stripes data (performance).

[hi]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select

[ HELP ]

Name : Volume0

RAID Level : RAID0(Stripe)

Disks : Select Disks

Strip Size : 128KB

Capacity : 111.7 GB

Create Volume

[ CREATE VOLUME MENU ]

Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 3.0.0.1184

The following are typical values:

RAID0 - 128KB

RAID10 - 64KB

RAID5 - 64KB
