- 15 - Hardware Installation
1-6 Internal Connectors
Read the following guidelines before connecting external devices:
•
First make sure your devices are compliant with the connectors you wish to connect.
•
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
•
After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) P12V_AUX1 11) PMBUS
2) DC_IN1 12) F_USB3
3) SATA0 13) COM1
4) SATA1 14) BP_1
5) SATA2 15) IPMB
6) SATA3 16) FP_1
7) SGPIO1 17) 80H
8) CPU0_FAN 18) BAT
9) SYS_FAN1
10) SYS_FAN2
DIMM_P0_A0
DIMM_P0_A1
DIMM_P0_B0
DIMM_P0_B1
CPU
17
1
7
16
14
11
13
