Hardware Installation
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
•
First make sure your devices are compliant with the connectors you wish to connect.
•
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
•
After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX1 11) SYS_FAN4
2) P12V_AUX1 12) SYS_FAN3
3) P12V_AUX2 13) SYS_FAN2
4) PMBUS 14) SYS_FAN1
5) CPU1_FAN 15) F_USB3
6) CPU0_FAN 16) FP_1
7) SYS_FAN5 17) BP_1
8) P12V_PCIE 18) IPMB
9) BAT 19) SPI_TPM
10) CPU1_FAN 20) Case Open Intrusion Alert Header
21) BMC Firmware Readiness LED
1
2
3
4
9
5
7
8
6
12
13
14
15
16
19
18
17
20
21
10
11
CPU1
CPU0
DIMM_P1_Q1 DIMM_P1_N0 DIMM_P1_M0 DIMM_P1_P0 DIMM_P1_O0 DIMM_P1_R0
DIMM_P1_T0 DIMM_P1_W0 DIMM_P1_X0 DIMM_P1_U0 DIMM_P1_V0 DIMM_P1_S0
DIMM_P0_B0 DIMM_P0_E0 DIMM_P0_F0 DIMM_P0_C0 DIMM_P0_D0 DIMM_P0_A0 DIMM_P0_K0 DIMM_P0_H0 DIMM_P0_G0 DIMM_P0_J0 DIMM_P0_I0 DIMM_P0_L 0
1-7-1 MZ73-LM0
