- 6 -
Item Code Description
1 SW_ID ID Button with LED
2 VGA VGA Port
3 COM1 Serial Port
4 LAN1 10GbE LAN Port #1
5 LAN2 10GbE LAN Port #2
6 USB3_MLAN Sever Management LAN Port (Top)/USB 3.2 Gen1 Ports (Bottom)
7 ATX1 2x12 Pin Main Power Connector
8 P12V_AUX1 2x4 Pin 12V Power Connector
9 P12V_AUX2 2x4 Pin 12V Power Connector
10 PMBUS PMBus Connector
11 U2_P1_P0B MCIO Connector (PCIe Gen4)
12 U2_P1_P0A MCIO Connector (PCIe Gen4)
13 CPU0_FAN CPU0 Fan Connector
14 SLSAS_0 Slimline Connector#0 (SATAIII 6Gb/s Signal)
15 CPU1_FAN CPU1 Fan Connector
16 SYS_FAN5 System Fan Connector #4
17 P12V_PCIE 2x3 Pin 12V Power Connector
18 BAT Battery Socket
19 CPU1_FAN CPU1 Fan Connector
20 SYS_FAN4 System Fan Connector #4
21 SYS_FAN3 System Fan Connector #3
22 SYS_FAN2 System Fan Connector #2
23 SYS_FAN1 System Fan Connector #1
24 F_USB3 Front Panel USB 3.2 Gen1 Connector
25 FP_1 Front Panel Header
26 BP_1 HDD Backplane Board Connector
27 M2_0 M.2 Slot(PCIe Gen4 x4, Support NGFF-2280/22110)
28 IPMB IPMB Connector
29 SPI_TPM TPM Connector
30 PCIe_1 PCIe x16 Slot #1(Gen5 x16)
31 PCIe_2 PCIe x16 Slot #2(Gen5 x16)
32 PCIe_3 PCIe x16 Slot #3(Gen5 x16)
33 PCIe_4 PCIe x16 Slot #4(Gen5 x16)
To Next Page
