20
www.gigaipc.com
No Code Description
10 LINE_OUT Line Out port (Green)
11 MIC_IN Mic In port (Pink)
12 CPU Socket 1 x LGA 1200 Socket
13 BKL_CN
Back Light Brightness Control Connector
14 EDP
Embedded Display Port connector
15 LSW
LVDS Resolution Jumper
16 Battery Battery Connector
17 LVDS LVDS Connector
18 FP_ Audio Front Panel Audio Header
19 SPKR Speaker out Connector
20
PCIEX16 1 x PCIe x16 (Gen3 x16 bus) slot
21 ATX_CTL
ATX Control Header, Support PS-ON Signal of
Power Supply Unit
22
COM2
COM header RS232
23 M2E M.2 Slot, E-Key, Supports NGFF-2230
24
AT_CN
AT/ATX power mode select jumper
25
SYS_FAN System Fan Connector
26
GPIO_CNT GPIO Connector
27 CLR_CMOS Clear CMOS Jumper
28 SATA_PWR1_2 SATA Power Connector x 2
29 SATA2, 3, 4 SATA 6 Gb/s Connector x 3
30 SYS_PANEL System Panel Header
31 F_USB2_1 USB 2.0 Header
32
F_USB2_2 USB 2.0 Header
