- Tighten the bushing of the flywheel lock tool on
the removing tool threading.
- Insert the special tool as shown in the figure,
making sure that the pins are perfectly inserted in-
to the previously aligned holes and that it is per-
fectly abutted and almost flush with the flywheel.
Specific tooling
020472Y Flywheel lock wrench
- Loosen the magneto flywheel fastening nut.
- Remove the special tool and the fastening nut.
- Remove the washer.
Engine Nexus 500 euro 3
ENG - 124
