020335Y Magnetic support for dial gauge
Front brake pads
Removal
- Remove the front brake calliper unscrewing the
2 retainers but leaving the hoses connected.
- Disengage the upper part of the pad from the seat
located into the calliper body.
- Using a calliper, remove the 2 retaining pins of
the pad sliding pin.
- Unscrew the retaining pin and the pads too.
- Check that the thickness of the friction material
is more than 1.5 mm.
- Otherwise, replace it.
Nexus 500 euro 3 Braking system
BRAK SYS - 319
