Centre-stand
- Remove the two return springs from the centre
stand.
- Loosen the fastening nuts.
- Remove the centre stand.
- On refitting tighten the nut to the specified torque.
Locking torques (N*m)
Central stand retainers 25 ÷ 30
Centre stand
We wish to inform you that from Chassis No. ZAPM3510000007012, a new centre stand has been
introduced to improve the function. The new stand differs from the old stand in having a 5 mm longer
stand arms, increasing the height of the scooter from the ground. The modification also requires the
introduction of a new stand stop buffer.
Side stand
- Unhook the springs.
- Loosen the nut.
- Pull out the screw.
Fitting
Carry out the previous operations but in reverse
order.
Locking torques (N*m)
Side stand clamp 15 ÷ 20
Nexus 500 euro 3 Suspensions
SUSP - 307
