Refitting the intake manifold
- Install the intake manifold on the engine.
- Insert the 3 fastening screws, one of which with
a support band for the cooling system sleeve, and
tighten to the prescribed torque.
Locking torques (N*m)
Inlet manifold screws 11 ÷ 13
Crankcase - crankshaft
- Remove the outside and inside transmission cov-
er and the complete driving pulley as described in
"Automatic transmission".
- Remove the flywheel cover with the cooling sys-
tem sleeves, as described in the "Flywheel cover"
chapter.
- Remove the flywheel with the starting system fol-
lowing the instruction given in "Flywheel and Start-
ing system".
Engine Nexus 500 euro 3
ENG - 164
