- Heat the bearing seat on the side the brake disc
with the heat gun.
2 - Insert the two bearings one at a time using the punch consisting of adaptor handle, 32x35 mm
adaptor and 15 mm guide, and take it to the stop.
Specific tooling
020376Y Adaptor handle
020357Y 32 x 35 mm adaptor
020412Y 15 mm guide
Refitting the front wheel
- When refitting, pay attention in repositioning the
odometer drive correctly.
Locking torques (N*m)
Wheel axle nut 45 ÷ 50 Wheel axle clamp
screws 6 - 7 Nm
Front fork
Removal
- Remove the front wheel.
- Remove the front mudguard
- Remove the front brake calliper
- Remove the front and rear handlebar covers.
- Remove the pin mounting the handlebar to the
steering tube.
- Remove the handlebar and rest it on the shield
back plate.
Nexus 500 euro 3 Suspensions
SUSP - 293
