- Tighten thoroughly the guide bushing of the fly-
wheel lock tool and loosen by 1/4 turn.
N.B.
FAILURE TO OBSERVE THIS RULE CAUSES THE LOCK-
ING OF THE GUIDE ON THE FLYWHEEL.
Specific tooling
020472Y Flywheel lock wrench
- Align the 2 holes of the flywheel with the case
housing to allow the introduction of the special tool.
- Insert the special tool checking that the pins are
perfectly introduced into the seat.
Specific tooling
020472Y Flywheel lock wrench
- Tighten the flywheel lock nut to the prescribed
torque.
Locking torques (N*m)
Flywheel fixing nut 115 - 125
Nexus 500 euro 3 Engine
ENG - 131
