The scooter has a "Power Drive" progressive rear suspension system combined with the "Direct Link"
system of engine mounting on the frame that gives exceptional rigidity to the whole system.
The scooter has a special connecting strut between engine and frame that allows the travel gear to be
adjusted to 15 positions.
If is thus possible by turning the ring nut on the lower part of the strut to raise or lower the rear section
of the scooter.
It is possible to adjust the geometry of the rear end to the preference of the rider and thus to adjust the
road bolding of the scooter:
- Lowers the rear section for improved stability at
higher speeds.
- Preference for a higher rear section to improve
handling and reduced speeds.
Removing the rear wheel
- Remove the muffler assembly.
- Remove the plastic plug from the wheel locking
nut
Nexus 500 euro 3 Suspensions
SUSP - 303
