Using the special tool, loosen and remove the up-
per ring nut, the spacer washer and the counter-
ring nut.
- Extract the fork.
N.B.
TAKE CARE TO SUPPORT THE FORK SO AS TO PREVENT
IT FROM COMING OFF ABRUPTLY
Specific tooling
020055Y Wrench for steering tube ring nut
Overhaul
Check pump unit
- Check that the oil holes on the pumping are free
from clogging.
- Check that the sealing snap ring is not damaged.
Check the spring length
- Check the length "A" of the spring.
Characteristic
Standard spring length:
291.6 mm
Servicing tapered bearing seats
- Check that the seats and the tapered bearings exhibit no scratches or wear.
N.B.
THE TAPERED BEARING SEATS SHOULD BE REMOVED ONLY IF STRICTLY NECESSARY.
Suspensions Nexus 500 euro 3
SUSP - 294
