IMMOBILIZER DECODER
Specification Desc./Quantity
1 -
2 Immobilizer LED control (negative)
3 Base power supply (positive)
4 Negative
5 -
6 Electronic control unit EMS (serial)
7 -
8 Continuous power supply (positive) Immobilizer aerial
EMS circuit diagram
KEY:
3. Engine rev sensor
4. Throttle valve position sensor
Injection Nexus 500 euro 3
INJEC - 196
