This section is devoted to the operations that can be carried out on the vehicle bodywork.
CAUTION
WE STRONGLY RECOMMEND NOT TO CLEAN THE PAINTED PLASTIC PARTS WITH SOLVENTS
CONTAINING PETROL OR PETROL BY-PRODUCTS.
Seat
- Remove the two clamping screws on the frame.
- Remove the control button of the undersaddle
light.
Rear handlebar cover
- Release the 3 locking tabs of the rear handlebar
cover shown in the figure using a screwdriver and
paying attention not to damage the paintwork.
- Remove the 5 mounting screws of the rear han-
dlebar cover.
N.B.
WHEN INSTALLING, THE CENTRE SCREW IS A METAL
SCREW, THE OTHER 4 ARE PLASTIC.
Chassis Nexus 500 euro 3
CHAS - 338
