Exhaust assy. Removal
- Loosen the two mountings of the exhaust mani-
fold at the cylinder head.
- Remove the Lambda probe from its support and
disconnect it.
Remove the screw indicated in the photograph.
- Loosen the screw shown in the figure so as to
loosen the muffler strap and remove the whole
muffler.
Nexus 500 euro 3 Engine from vehicle
ENG VE - 79
