Front tyre Tubeless 120/70-14'' 55P
Rear tyre Tubeless 140/60-13'' 63P
ENGINE SPECIFICATIONS
ENGINE Single-cylinder, four-stroke
Bore x stroke 57 x 48.6 mm
Engine capacity 124 cm³
Compression ratio 11.5 ÷ 12.5 : 1
Variable ignition advance (before
TDC) 125
Variable
Idle speed ~ 1650 ± 100 rpm
Max. power 11.0 kW at 9,750 rpm
MAX. torque 12.0 Nm at 8000 rpm
DEPRESSION CARBURETTOR KEIHIN CVK 30
Spark plug CHAMPION RG 4HC - NGK CR 8
EB
Fuel system with unleaded petrol; carburettor
and electrical pump.
Timing system single overhead camshaft driven
by a chain on the left-hand side, 4
valves, three-arm rocking lever
with set screw.
70
