03_14
Fuses (03_14)
The electrical system is protected by a fuse, «B», located next to the battery. The
following sub-systems are not protected by the fuse: ignition, headlight, sidelights, and
taillight. If you experience a second fuse failure after replacing a burst fuse, please
contact an Authorised Piaggio Service Station to investigate the fault. Do not at-
tempt to close the circuit with any material other than the fuse.
Electric characteristic
Main fuse
7.5 A
LIGHT BULBS TABLE
Low-beam bulb Type: H8
Power: 12V - 35W
Quantity: 1
High-beam light bulb Type: H8
Power: 12V - 35W
Quantity: 1
Front tail light bulb Type: All glass
Power: 12V - 3W
Quantity: 2
Front turn indicator light bulb Type: Spherical
42
