Power: 12V - 10W
Quantity: 1 RHS + 1 LHS
Rear turn indicator light bulb Type: Spherical
Power: 12V - 10W
Quantity: 1 RHS + 1 LHS
Stop light bulb Type: SPHERICAL
Power: 12V - 10W
Quantity: 2
Rear tail light bulb Type: All glass
Power: 12V - 3W
Quantity: 2
03_15
Frontlightgroup (03_15, 03_16, 03_17)
In order to reach the headlamp bulb remove the snap-on Gilera shield by inserting the
blade of a small screwdriver in the corresponding lateral notch, paying attention not
to scratch the paint. Then loosen the screw underneath and lift up the front shield
centre cover.
Then follow this procedure:
High and low beam bulb:
1. remove the rear cover and take the bulb holder; then turn it up around 30º;
2. disconnect the bulb connector and change the bulb.
Tail lights:
43
