Chapter 7 Software
When you have completed and fully understood all the contents mentioned above, you can really
start to use this system integrating Wilson system and Frank system into a whole.
Notice: The device is a standard 12-lead sync sampling device, so it always chooses
"12-lead" under any interface that need to choose from Wilson "12-lead", "15-lead" or
"18-lead".
Double-click "ECG Workstation" icon on the Desktop to enter to the interface shown as Figure 19.
C
lick h
ere to
select a case
Figure 19
Let's see each part in the main interface. First, at the top of the software is the menu, including
