The fabric is loose when the awning is fully extended; i.e. the roller keeps turning after
the awning arms have locked open.
SOLUTION:
The motors OUT limits must be reset to factory standards. Please refer to the
“Adjusting the Motors Limit Switches” section on page__
PROBLEM:
The motor stops before the lead rail has closed completely into the awning cassette on
either or both sides. There is no apparent binding of the awning components.
SOLUTION:
The NOVA Awning is equipped with a manual override motor which has manual limit
settings. The IN limit may need to be adjusted to allow the box to be closed tighter.
“Adjusting the Motors Limit Switches” section on page 19-20.
PROBLEM:
As the awning is closing, the elbow of one or more of the arms is hanging down
preventing the case from closing.
SOLUTION:
Please refer to the “Adjusting pitch and Arm (Elbow) Heighth on page 21-22.
WARRANTY LABOR TIME GUIDELINES
LABOR TO BE PERFORMED TIME ALLOWED
COMPLETE AWNING REPLACEMENT (WALL) 2
hrs.
COMPLETE AWNING REPLACEMENT (ROOF) 2
hrs.
FABRIC REPLACEMENT (WALL)
1hr.
FABRIC REPLACEMENT (ROOF)
2 hrs.
MOTOR REPLACEMENT (WALL)
2 hrs.
MOTOR REPLACEMENT (ROOF)
3.5 hrs.
LATERAL ARM REPLACEMENT (PER ARM)
1 hr.
