GIRBAU LOGI CONTROL User Manual

LOGI CONTROL. Advanced mode 34
Cod. 523340
Rev. 10/1016
6.5.3. Definition of programmable functions and values for each phase
FUNCTION
CONCEPT
OPTIONS
Ph
Phase execution
Ph-Y
Phase can be executed
Ph-N
Phase cannot be executed
L
Bath level
L-1
Low level
L-2
Medium level
L-3
High level (level not programmable in machines with pump
drain or valve closed without current)
L-4
Extra high level
(level not programmable in machines with pump drain or valve
closed without current)
C / F
Temperature of the
bath
0 /
**
Programmable range in degrees Celsius
32 /
***
Programmable range in degrees Fahrenheit
n.p
Not possible to program temperature in phase
d
Dosings
d-0
Phase without dosing
d-1
Dosing via pre-wash compartment
Pre-wash external dosing signal
d-2
Dosing via wash compartment
Wash external dosing signal
d-3
Dosing via whitening compartment
Whitening external dosing signal
d-4
Dosing via softener or neutraliser compartment
Softener or neutraliser external dosing signal
r
Rotation sequence
r-1
Vigorous rotation sequence: 25 sec. ON - 5 sec. OFF
r-2
Normal rotation sequence: 15 sec. ON - 15 sec. OFF
r-3
Light rotation sequence: 25 sec. ON - 5 sec. OFF
rt
Rotation time
(in minutes)
1...12
Programmable range in soak, pre-wash and rinse phases
1...20
Programmable range in the wash phase
c
Gradual cool down
0
Without gradual cool-down
1
Gradual cool-down in wash phase
n.p
Option not programmable
rh
Program stop in final
rinse
0
Without stop in final rinse
1
Stop in final rinse
n.p
Option not programmable
E
Bath drain
0
Access to the next phase without draining in the bath
1
Drain + wash speed
2
Drain + positioning speed
3
Drain + low extract speed
4
Drain + medium spin speed
5
Drain + medium/high extract speed
6
Drain + high spin speed
Et
Extract time
**
Time in minutes.
