GIRBAU LOGI CONTROL User Manual

LOGI PRO. Operation 48
Cod. 523340
Rev. 10/1016
7.2. Interpretation of the program tables
SYMBOL
OPTION
DESCRIPTION

**
Estimated program time
Minimum program time based on a machine with hot water supply and without
heating. Time in minutes.
Ph
**
Phase number
The phase indicated with a grey background belongs to the wash phase.
Y / N
Y
N
Phase execution
Phase can be executed
Phase cannot be executed
L
(see note in
Section
8.5.3)
0
1
2
3
4
5
6
Bath level
Without water inlet
Low level
Medium low level
Medium level
Medium high level
High level
Extra high level
C / F
**
Temperature of the bath
Value in degrees Celsius or Fahrenheit
1d
0
1
2
3
4
First dosing
No dosing
Dispensing via Compartment 1 (solid product)
Dispensing via Compartment 2 (solid product)
Dispensing via Compartment 3 (liquid product)
Dispensing via Compartment 4 (liquid product)
dt
**
First dosing time
Value in seconds (see note in section 8.5.3)
2d
**
Second dosing
The same parameters as in the first dosing
dt
**
Second dosing time
Value in seconds
r
no
Lo
Md
Hi
Drum rotation sequence
No rotation in the phase
Light rotation sequence: 5 sec. ON / 25 sec. OFF
Normal rotation sequence: 15 sec. ON / 15 sec. OFF
Vigorous sequence rotation: 25 sec. ON / 5 sec. OFF
rt
**
Rotation time
Value in minutes
c
0
1
Gradual cool down
Option not available
Option available
rh
0
1
Program stop
Option not available
Option available
E
0
1
2
4
6
Bath drain
Access to the next phase without draining in the bath
Drain + wash speed
Drain + positioning speed
Drain + medium spin speed
Drain + high spin speed
Et
**
- - - -
Spin time
Value in minutes
Non programmable function in the phase
