GIRBAU LOGI CONTROL User Manual

LOGI PRO. Advanced mode 62
Cod. 523340
Rev. 10/1016
8.5. Modifying a program
8.5.1. Programming vectors
PHASE
Ph
L
C / F
1d
dt
2d
dt
r
rt
c
rh
E
Et
1…10
Y / N
0…6
0 ... 90
32 ... 194
0…4
1…99
0…4
1…99
no, Lo,
Md, Hi
0...20
0 / 1
0 / 1
0 / 1…6
n.p. 2...9
11
Y
0…6
0 ... 90
32 ... 194
0…4
1…99
0…4
1…99
no, Lo,
Md, Hi
0...20
0 / 1
0 / 1
1…6
n.p. 2...9
8.5.2. Definition of programmable functions and values for each phase
FUNCTION
CONCEPT
OPTIONS
Ph
Phase execution
Ph-Y
Phase can be executed
Ph-N
Phase cannot be executed
L
Bath level
(see note in Section 8.5.3)
L-0
Without water inlet
L-1
Low level
L-2
Medium low level
L-3
Medium level
L-4
Medium high level
L-5
High level
L-6
Extra high level
C / F
Temperature of the bath
0 / 90
Programmable range in degrees Celsius
32 / 194
Programmable range in degrees Fahrenheit
1d
First dosing
1d-0
Phase without dosing
1d-1
Dosing via compartment 1 (powder)
External dosing signal 1
1d-2
Dosing via compartment 2 (powder)
External dosing signal 2
1d-3
Dosing via compartment 3 (liquid)
External dosing signal 3
1d-4
Dosing via compartment 4 (liquid)
External dosing signal 4
t
First dosing time
0 / 99
Value in seconds (see note in section 8.5.3)
2d
Second dosing
2d-
*
The same parameters as in the first dosing
t
Second dosing time
1 / 99
Value in seconds
r
Rotation sequence
no
No rotation in the phase
Lo
Light rotation sequence: ON: 5 sec. / OFF: 25 sec.
Md
Normal rotation sequence: ON: 15 sec. / OFF: 15 sec.
Hi
Vigorous rotation sequence: ON: 5 sec./ OFF: 25 sec.pm
rt
Rotation time
1...20
Value in minutes
c
Gradual cool down
0
Without gradual cool-down
n.p
Gradual cool-down activated
rh
Program stop
0
Without program stop
1
Program stop activated
E
Bath drain
0
Access to the next phase without draining in the bath
1
Drain + wash speed
2
Drain + positioning speed
3
Drain + low extract speed
4
Drain + medium spin speed
5
Drain + medium/high extract speed
6
Drain + high spin speed
Et
Extract time
**
Time in minutes.
