Gliderol Glidermatic GTS+ - Stage 3 - Lock Track to Power Unit; Stage 4 - Attach Track to Lintel Bracket

Glidermatic GTS+ Installation Instructions & owner’s manual Page 4
Stage 3 - Lock Track to Power Unit
 Place the 2 x ‘U’ brackets over the track and slot holes into threaded studs.
 Place and tighten brackets with M6 nuts provided.
Stage 4 - Attach Track to Lintel Bracket
 Slot the other end of the track between the flanges of the installed lintel bracket.
 Insert large pin provided and lock with ‘R’ Clip.
