TECHNICAL SPECIFICATIONS
Antenna dimensions (diam.x H): 250 x 300 mm / 10x12"
Antenna weight: 1 kg / 2,2 lb
DUAL MICRO SIM system
Automatic switch Wi-Fi registered networks to 5G/4G
Automatic APN
SMS management function
V-SAT/SAT internet autoswitch mode
Switching cellular data to external Wi-Fi
Encrypted real-time peer-to-peer connection for remote set-up and service
5G/4G backup WAN function
5G: up to 2.5Gbps in download
LTE CAT16 DWN: up to 1Gbps in download
DC- HSPA+ up to 42 Mbps in download
Power Supply: 9/30 Vdc
Average Consumption: 450mA (max. 1A)
GENERAL FEAUTURES
IT1205PLUS - WORLDWIDE (escl. Cina)
Operating temperature: from -40°C to 75°C
5G NR: n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n66/n71/n77/
n78/n79 - n48 in process
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12(B17)/B13/B14/B18/B19/B20/B25
/B26/B28/B29/B30/B32/ B66/B71
LTE-TDD: B34/B38/39/B40/B41/B42/B43/B48 LAA: B46 (supports only 2 × 2
MIMO)
WCDMA: B1/B2/B3/B4/B5/B6/B8/B19
