7
3. INSTALLATION
WARNING
Fig. 1
Fig. 2
We recommend not to install the antenna at the same level of the radar, as the
radar’s energy could damage the antenna. The antenna should be positioned at a
distance of at least 1.5m (5') from the other transmitting antennas (VHF, radar)
Installation on sailboat
It is advisable to place the weBBoat® Plus 5G to a maximum height of 8/10m
(26/33') on the spreader with the Glomex mount code ITM001 (not supplied).
a
The weBBoat® Plus 5G must be fixed to the mount by tightening the screw on the
bottom of weBBoat® Plus 5G with a screwdriver (Fig. 2).
IMPORTANT: Do not install the weBBoat® Plus 5G at the masthead.
