Appendix
46 Installation and maintenance instructions EASICOM 3 0020239562_02
Technical data – Domestic hot water
EASICOM 3 24c EASICOM 3 28c
Specific flow rate (D) (ΔT = 30 K)
in accordance with EN 13203
11.7 l/min 13.6 l/min
Continuous flow rate (ΔT = 35 K)
602 l/h 699 l/h
Specific flow rate (ΔT = 35 K)
10.0 l/min 11.7 l/min
Minimum permissible pressure
0.03 MPa
(0.30 bar)
0.03 MPa
(0.30 bar)
Maximum permissible pressure
1 MPa
(10 bar)
1 MPa
(10 bar)
Temperature range
35 … 60 ℃ 35 … 60 ℃
Flow rate limiter
8 l/min 10 l/min
Technical data – General
EASICOM 3 24c EASICOM 3 28c
Diameter of the gas pipe
1/2 inch 1/2 inch
Diameter of the heating pipe
3/4 inch 3/4 inch
Expansion relief valve connector
(min.)
15 mm 15 mm
Condensed water discharge pipe
(min.)
21.5 mm 21.5 mm
G20 gas supply pressure
20 mbar 20 mbar
Gas flow at P max. – hot water
(G20)
2.6 m³/h 3.0 m³/h
CE number (PIN)
CE-0063CP3646 CE-0063CP3646
Smoke mass flow in heating mode
at P min.
2.34 g/s 2.80 g/s
Smoke mass flow in heating mode
at P max.
9.2 g/s 11.1 g/s
Smoke mass flow in hot water
handling mode at P max.
11.1 g/s 12.9 g/s
Nominal efficiency at 80/60 °C
98.9 % 99 %
Nominal efficiency at 50/30 °C
104 % 104 %
Nominal efficiency in partial load
operation (30%) at 40/30 °C
109.8 % 108.5 %
NOx class
5 5
Product dimensions, width
418 mm 418 mm
Product dimensions, depth
300 mm 300 mm
Product dimensions, height
740 mm 740 mm
Net weight
32 kg 32.6 kg
Weight when filled with water
36 kg 37.1 kg
Technical data – Electrics
EASICOM 3 24c EASICOM 3 28c
Electric connection
230 V / 50 Hz 230 V / 50 Hz
Built-in fuse (slow-blow)
T2/2A, 250V T2/2A, 250V
Max. power consumption
105 W 110 W
Standby electrical power con-
sumption
2 W 2 W
Level of protection
IPX4D IPX4D
Note
The lowest nominal heat output may be higher than the value in the technical data, depending on the design of the
system and the current operating status.
