Appendix
0020283671_03 Energy 2 Installation and maintenance instructions 33
Dia-
gnostics
code
Parameter
Values
Unit Increment, select, explanation
Default set-
ting
Own setting
Min. Max.
d.90 Status of the eBUS room
thermostat
Current value – off = Not connected
on = Connected
– Not
adjustable
d.91 Status DCF77 Current value – – – Not
adjustable
d.93 Setting the product code 0 99 – 1
The Device Specific Number
(DSN) can be found on the iden-
tification plate.
– Adjustable
d.94 Delete fault list 0 1 – off = No
on = Yes
– Adjustable
d.95 Software versions – – – 1 = Main PCB
2 = Interface PCB
– Adjustable
d.96 Default setting (reset) – – – 0 = No
1 = Yes
– Adjustable
C Status codes – Overview
Note
Since the code table is used for various products, some codes may not be visible for the product in question.
Status code Meaning
Displays in heating mode
S.0 Heating mode: No requirement
S.01 Heating mode: Fan prerun
S.02 Heating mode: Pump prerun
S.03 Heating mode: Burner ignition
S.04 Heating mode: Burner on
S.05 Heating mode: Pump/fan overrun
S.06 Heating mode: Fan overrun
S.07 Heating mode: Pump overrun
S.08 Heating mode: Temporary shutdown after heating procedure
Displays in domestic hot water mode
S.10 Domestic hot water mode: Requirement
S.11 Domestic hot water mode: Fan prerun
S.13 Domestic hot water mode: Burner ignition
S.14 DHW mode: Burner on
S.15 DHW mode: Pump/fan overrun
S.16 DHW mode: Fan overrun
S.17 DHW mode: Pump overrun
Display in comfort mode with warm start or domestic hot water mode with cylinder
S.20 Domestic hot water mode: Requirement
S.21 Domestic hot water mode: Fan prerun
S.22 Domestic hot water mode: Pump prerun
S.23 Domestic hot water mode: Burner ignition
S.24 DHW mode: Burner on
S.25 DHW mode: Pump/fan overrun
S.26 DHW mode: Fan overrun
S.27 DHW mode: Pump overrun
S.28 Domestic hot water mode: Temporary shutdown of the burner
Other displays
