GLOW T180 - 2. Technical Characteristics; 2.1 Technical Data

Glow T180
Tankless Condensing Water Heater
12
2. Technical Characteristics
2.1 Technical Data
Table 2.1
Glow T180
Natural Gas Propane
Heat Input (Max) Btuh (kW) 194,000 (56.8) 194,000 (56.8)
Heat Input (Min) Btuh (kW) 20,500 (6.0) 20,500 (6.0)
Energy Factor (EF)
97%
95%
Unified Energy Factor (UEF)
95%
93%
Domestic Hot Water
Heat Output (Max) Btuh (kW) 188,000 (55.1) 188,000 (55.1)
Hot Water Temperature Setting (min-max) °F (°C) 102-145 (39-63)
Maximum Water Pressure Psig (bar) 150 (10.3)
Minimum Water Pressure Psig (bar) 30 (2.1)
DHW Flow at ∆T 35°F usgpm (lpm) 10.7 (40.2)
DHW Flow at ∆T 45°F usgpm (lpm) 8.4 (31.8)
DHW Flow at ∆T 72°F usgpm (lpm) 5.2 (19.7)
DHW Flow at ∆T 77°F usgpm (lpm) 4.9 (18.6)
Minimum Activation Flow Rate usgpm (lpm) 0.6 (2.27)
Dimensions (casing size)
Width In (mm) 16 ¾ (425)
Height In (mm) 24 ⅜ (619)
Depth In (mm) 17 ¼ (438)
Weight (NET) Lbs (Kg) 86 (39)
Weight (GROSS) Lbs (Kg)
90 (41)
Connections
Cold Water In MPT
¾”
Hot Water Out MPT ¾”
Gas Inlet Connection MPT ¾”
Gas Supply
Inlet Pressure (min-max) inch. wc. 3.5-10 8-13
Gas Valve Outlet Pressure inch. wc. -0.03 -0.03
Electrical Specification
Power Supply
V/Hz
120/60
Electrical Power Consumption
W
119
General
Installation Type
Indoor Wall Hung
Venting Type
Forced Draft Direct Vent
Ignition
Electronic Ignition
Venting
Exhaust
inch
2, 2 ½, 3 in PVC, CPVC
Intake
inch
2, 2 ½, 3 in PVC, CPVC, ABS
Vent Clearances
inch
0 in to combustibles
Safety Devices
Ionization Electrode, Ignition Software, Water Temperature
Sensors, Flue Temperature Sensor and Fuse, High Limit
Switch, Blocked Flue Switch & Power Fuse.
