GLP JDC1 - Page 12

WWW.GLP.DE JDC1
12 User Manual Rev. 1.0
Menu Selection
Value
Remarks
DMX Start Address
1-512
Set the DMX start address
Setup
DMX Mode
M01 COMPRESS
-
Compressed 14-channel mode
M02 NORMAL
-
Normal 23-channel mode
M03 SPIX
-
High resolution 68-channel mode
M04 SPIXPRO
-
High resolution 62-channel mode
M05 1PIXPRO
-
Low resolution 17-channel mode
Settings
Tilt
Invert Tilt
ON/OFF
Invert tilt control
Position Feedback
ON/OFF
Toggle feedback
Tilt Enable
ON
-
Tilt enabled and DMX controllable
OFF
-
Tilt disabled
NC
-
Tilt enabled, not DMX controllable
Shutter
Error Blackout
ON/OFF
Blackout in case of error
No DMX Blackout
ON/OFF
Blackout if no DMX for 3 seconds
Init Positions
Save
-
Save as initial positions
Reset
-
Restore default positions
Dimming Curve
Linear
-
Soft
-
Extra Soft
-
DMX Hold
Off
-
Blackout on loss of DMX
Fade Out
-
Fade out on loss of DMX
Hold
-
Hold state on loss of DMX
PWM Frequency
Adjust pulse width modulation freq.
582-618 Hz
-
Default = 600 Hz
1200 Hz
-
2400 Hz
-
FX Pattern Priority
ON/OFF
Display
Contrast
0-100%
Default = 50%
Brightness
0-100%
Default =100%
Blackout Time
1-30 s
Display off (seconds after keypress)
Display Orientation
Normal
-
Normal display
Inverted
-
Inverted display
No DMX Flash
ON/OFF
Toggle flash on DMX loss
Temperature Unit
°C/°F
Fan Mode
Auto
-
Temperature controlled fan speed
High
-
Maximum cooling
Reset Factory Settings
Yes/No
Resets all values except serial number
