GLP JDC1 - DMX Mode 1: Compressed Pro (14 Channels)

WWW.GLP.DE JDC1
16 User Manual Rev. 1.0
5.1 Mode 1, Compressed Pro, 14 DMX Channels
Channel
Command
Percent
DMX
1
Coarse Tilt (MSB)
0-182°
0-100%
0-255
2
Fine Tilt (LSB)
coarse tilt + 0-1.2°
0-100%
0-255
3
Beam Intensity
blackout to full
0-100%
0-255
4
Beam Duration
7-650 ms
0-100%
0-255
5
Beam Rate
0.289-16.67 Hz
0-100%
0-255
6
Beam FX Shutter
no effect
0-14.0%
0-36
ramp up (= fade on, snap off)
14.5-15.5%
37-40
ramp up random
16.0-17.0%
41-44
ramp down
17.5-18.5%
45-48
ramp down random
19.0-20.0%
49-52
ramp up down
20.5-21.5%
53-56
ramp up down random
22.0-23.0%
57-60
random white beam
23.5-24.5%
61-64
random single pixel of the white beam
25.0-26.0%
65-68
lightning
26.5-27.5%
69-72
spikes (flash over low light)
28.0-29.0%
73-76
white beam, left to right
30.0-31.5%
77-80
white beam, left to right, random
32.0-33.0%
81-84
white beam, right to left
33.5-34.5%
85-88
white beam, right to left, random
35.0-36.0%
89-92
white beam, left to right, bounce
36.5-37.5%
93-96
white beam, left to right, bounce, random
38.0-39.0%
97-100
white beam, right to left, bounce
39.5-40.5%
101-104
white beam, right to left, bounce, random
41.0-42.5%
105-108
zig, 6 steps
43.0-43.5%
109-112
zig, 6 steps, random
44.0-45.5%
113-116
zig, 6 steps, outer to center pixel
46.0-47.0%
117-120
zig, 6 steps, outer to center pixel, random
47.5-48.5%
121-124
zigzag, 10 steps
49.0-50.0%
125-128
zigzag, 10 steps, random
50.5-52.0%
129-132
reserved
52.5-70.0%
133-179
double flash
70.6-71.8%
180-183
double flash, random
72.2-73.3%
184-187
double flash, beam-color
73.7-74.9%
188-191
double flash, beam-color, random
75.3-76.5%
192-195
double flash, color-beam
76.9-78.0%
196-199
double flash, color-beam, random
78.4-79.6%
200-203
triple flash
80.0-81.2%
204-207
triple flash, random
81.6-82.7%
208-211
triple flash, beam-color-beam
83.1-84.3%
212-215
triple flash, b-c-b, random
84.7-85.9%
216-219
triple flash, c-b-c
86.3-87.5%
220-223
triple flash, c-b-c, random
87.8-89.0%
224-227
quad flsh
89.4-90.6%
228-231
quad flash, random
91.0-92.2%
232-235
quad flash, b-c-b-c
92.5-93.7%
236-239
quad flash, b-c-b-c, random
94.1-95.3%
240-243
quad flash, c-b-c-b
95.7-96.9%
244-247
quad flash, c-b-c-b, random
97.3-98.4%
248-251
reserved
98.5-100%
252-255
