GLP JDC1 - DMX Mode 4: SPix Pro (62 Channels)

German Light Products GmbH JDC1
User Manual Rev. 1.0 21
5.4 Mode 4, SPix Pro, 62 DMX Channels
Channel
Command
Percent
DMX
See Mode 1 for Channels 1-14
15
Pixel 1
Red
0-100%
0-255
16
Green
0-100%
0-255
17
Blue
0-100%
0-255
18
Pixel 2
Red
0-100%
0-255
19
Green
0-100%
0-255
20
Blue
0-100%
0-255
21
Pixel 3
Red
0-100%
0-255
22
Green
0-100%
0-255
23
Blue
0-100%
0-255
24
Pixel 4
Red
0-100%
0-255
25
Green
0-100%
0-255
26
Blue
0-100%
0-255
27
Pixel 5
Red
0-100%
0-255
28
Green
0-100%
0-255
29
Blue
0-100%
0-255
30
Pixel 6
Red
0-100%
0-255
31
Green
0-100%
0-255
32
Blue
0-100%
0-255
33
Pixel 7
Red
0-100%
0-255
34
Green
0-100%
0-255
35
Blue
0-100%
0-255
36
Pixel 8
Red
0-100%
0-255
37
Green
0-100%
0-255
38
Blue
0-100%
0-255
39
Pixel 9
Red
0-100%
0-255
40
Green
0-100%
0-255
41
Blue
0-100%
0-255
42
Pixel 10
Red
0-100%
0-255
43
Green
0-100%
0-255
44
Blue
0-100%
0-255
45
Pixel 11
Red
0-100%
0-255
46
Green
0-100%
0-255
47
Blue
0-100%
0-255
48
Pixel 12
Red
0-100%
0-255
49
Green
0-100%
0-255
50
Blue
0-100%
0-255
51
White Intensity
Pixel 1
0-100%
0-255
52
Pixel 2
0-100%
0-255
53
Pixel 3
0-100%
0-255
54
Pixel 4
0-100%
0-255
55
Pixel 5
0-100%
0-255
56
Pixel 6
0-100%
0-255
57
Pixel 7
0-100%
0-255
58
Pixel 8
0-100%
0-255
59
Pixel 9
0-100%
0-255
60
Pixel 10
0-100%
0-255
61
Pixel 11
0-100%
0-255
62
Pixel 12
0-100%
0-255
