5.5 Mode 3, SPix, 68 DMX Channels
Channel
Command
Percent
DMX
See Mode 1 for Channels 1-14
15
FX Crossfade
0-100%
0-255
16
Pattern Color Movement
0-100%
0-255
17
Pattern Select Color
0-100%
0-255
18
Pattern Beam Movement
0-100%
0-255
19
Pattern Select Beam
0-100%
0-255
20
Master Pix Intensity
0-100%
0-255
21
Pixel 1
Red
0-100%
0-255
22
Green
0-100%
0-255
23
Blue
0-100%
0-255
24
Pixel 2
Red
0-100%
0-255
25
Green
0-100%
0-255
26
Blue
0-100%
0-255
27
Pixel 3
Red
0-100%
0-255
28
Green
0-100%
0-255
29
Blue
0-100%
0-255
30
Pixel 4
Red
0-100%
0-255
31
Green
0-100%
0-255
32
Blue
0-100%
0-255
33
Pixel 5
Red
0-100%
0-255
34
Green
0-100%
0-255
35
Blue
0-100%
0-255
36
Pixel 6
Red
0-100%
0-255
37
Green
0-100%
0-255
38
Blue
0-100%
0-255
39
Pixel 7
Red
0-100%
0-255
40
Green
0-100%
0-255
41
Blue
0-100%
0-255
42
Pixel 8
Red
0-100%
0-255
43
Green
0-100%
0-255
44
Blue
0-100%
0-255
45
Pixel 9
Red
0-100%
0-255
46
Green
0-100%
0-255
47
Blue
0-100%
0-255
48
Pixel 10
Red
0-100%
0-255
49
Green
0-100%
0-255
50
Blue
0-100%
0-255
51
Pixel 11
Red
0-100%
0-255
52
Green
0-100%
0-255
53
Blue
0-100%
0-255
54
Pixel 12
Red
0-100%
0-255
55
Green
0-100%
0-255
56
Blue
0-100%
0-255
57
White Intensity
Pixel 1
0-100%
0-255
58
Pixel 2
0-100%
0-255
59
Pixel 3
0-100%
0-255
60
Pixel 4
0-100%
0-255
61
Pixel 5
0-100%
0-255
62
Pixel 6
0-100%
0-255
63
Pixel 7
0-100%
0-255
64
Pixel 8
0-100%
0-255
65
Pixel 9
0-100%
0-255
66
Pixel 10
0-100%
0-255
67
Pixel 11
0-100%
0-255
68
Pixel 12
0-100%
0-255
