GLP JDC1 - PWM Frequency and DMX Modes

WWW.GLP.DE JDC1
18 User Manual Rev. 1.0
7
Special / Control
PWM Frequency
582 Hz
39.2-40.0%
100-102
583 Hz
40.4-41.2%
103-105
584 Hz
41.6-42.0%
106-107
585 Hz
42.4-43.1%
108-110
586 Hz
43.5 43.9%
111-112
587 Hz
44.3 -45.1%
113-115
588 Hz
45.5-46.3%
116-118
589 Hz
46.7-47.1%
119-120
590 Hz
47.5-48.2%
121-123
591 Hz
48.6-49.0%
124-125
592 Hz
49.4-50.2%
126-128
593 Hz
50.6-51.4%
129-131
594 Hz
51.8-52.2%
132-133
595 Hz
52.5-53.3%
134-136
596 Hz
53.7-54.1%
137-138
597 Hz
54.5-55.3%
139-141
598 Hz
55.7-56.5%
142-144
599 Hz
56.9-57.3%
145-146
600 Hz
57.6-58.4%
147-149
601 Hz
58.8-59.2%
150-151
602 Hz
59.6-60.4%
152-154
603 Hz
60.8-61.6%
155-157
604 Hz
62.0-62.4%
158-159
605 Hz
62.7-63.5%
160-162
606 Hz
63.9-64.3%
163-164
607 Hz
64.7-65.5%
165-167
608 Hz
65.9-66.7%
168-170
609 Hz
67.1-67.5%
171-172
610 Hz
67.8-68.6%
173-175
611 Hz
69.0-69.4%
176-177
612 Hz
69.8-70.6%
178-180
613 Hz
71.0-71.8%
181-183
614 Hz
72.2-72.5%
184-185
615 Hz
72.9-73.7%
186-188
616 Hz
74.1-74.5%
189-190
617 Hz
74.9-75.7%
191-194
618 Hz
76.1-76.1%
194-194
1200 Hz
76.5-77.3%
195-197
2400 Hz
77.6-78.4%
198-200
No Function
79.0-82.0%
201-209
Duration Percentage Mode On
82.5-84.0%
210-214
Duration Percentage Mode Off
84.5-85.0%
215-219
Dimmer Flash On
86.0-87.5%
220-224
Dimmer Flash Off
88.0-90.0%
225-229
FX/Plate Color Priority On
90.5-91.5%
230-234
FX/Plate Color Priority Off
92.0-93.5%
235-239
No Function
94.0-97.0%
220-247
Reset (Hold > 5 seconds)
98.0-100%
248-255
