GlucoRx HCT - Display Screen; Test Strip

12
Display Screen
Ketone Symbol / Ketone Warning
Glucose Level / Ketone Level
Error Warning
Low Battery Symbol
Day Average
Memory Symbol
Time / Date
HCT Level
Glucose / Ketone Measurement
Unit
Measurement Modes
Gen – any time of day
AC – before meal
PC – after meal
1
2
3
4
5
6
7
9
8
10
Test Strip Symbol
Blood Drop Symbol
Code
Glucose Symbol
Alarm reminder
12
11
13
14
15
ATTENTION:
The front side of test strip should
face up when inserting test strip.
Test results may be wrong if the contact
bar is not fully inserted into the test slot.
NOTE:
The GlucoRx HCT monitor should only be used with GlucoRx HCT Glucose
or β-Ketone Test Strips. Using other test strips with this meter can produce
inaccurate results.
Test Strip
1
Absorbent Hole
Conrmation Window
1
2
Test Strip Handle
Contact Bars
3
4
3
4
(for glucose test) (for ketone test)
2
13 12 11
1
14
3
7
2
4
5
6
10
8
9
15
(characterised as "AL1",
"AL2", "AL3", "AL4" in the
middle of meter display)
