Item Number Item Remarks
15 Transmission* Fill to level of filler plug.
15 Transmission-Automatic*,**,† Check fluid level.
16 Propshaft Slip Joints
One fitting each joint; lubricate with
GM Part No. 1051344 Wheel Bearing Lubricant.
17 Propshaft U-joints
One fitting each joint (1480 and 1550 Series);
lubricate with GM Part No. 1051344 Wheel Bearing
Lubricant. Two fittings each joint (1610 Series and
larger); lubricate with GM Part No. 1051344 Wheel
Bearing Lubricant.
18 Rear Wheel Bearings* Hand-pack or lubricate.
19 Rear Axle* Fill to level of filler plug.
20 Parking Brake Clevis Pin$ Apply chassis lubricant.
21 Master Cylinder$ Fill 1/4 inch (6 mm) below opening.
22 Parking Brake Lever Pivot**, $ Apply chassis lubricant.
23 Clutch Release Cross Shaft** One fitting each.
* Refer to Maintenance Schedule.
** Applies to some vehicles.
*** Applies to air brakes only.
† Refer to Allison Transmission
®
Operator’s Manual.
$ Applies to hydraulic brakes only.
234
