Power Windows and Other Power
Options
Circuit breakers in the fuse panel protect the
power windows and other power accessories.
When the current load is too heavy, the circuit
breaker opens. This protects the circuit until
the current load returns to normal or the
problem is fixed.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected
from short circuits by a combination of fuses,
circuit breakers, maxi-fuses and fusible links.
This greatly reduces the chance of a fire caused
by an electrical problem. There may be a fuse
taped to the wiring harness near the hydraulic
brake booster.
Before changing a fuse, turn the ignition off and
set the parking brake.
Instrument Panel Fuse Block
The instrument panel fuse block is located on the
top of the instrument panel on the passenger’s
side of the vehicle.
To access the fuse block, remove the cover by
lifting up on the front and turning it backward.
To reinstall the cover, put the tabs at the rear
of the cover into the slots on the instrument panel
and lower the cover down to snap into place.
277
