SECTION III GETTING STARTED
2005 Tech 2 User’s Guide III - 2
Initial Hardware Installation
The Tech 2 hardware initial installation requires the following seven tasks:
1. Remove the RS-232 loopback adapter (P/N 3000112) from the storage case (P/N 3000116). Plug it into
the RS-232 port (Figure III-2).
2. Attach the Tech 2 DLC cable (P/N 3000095) to the VCI connector (Figure III-3).
3. Locate the DLC loopback adapter (P/N 3000109) in the storage case. Attach it to the DLC cable
(Figure III-4).
4. Locate the NAO (P/N 3000113) or Universal (P/N 3000115) power supply and appropriate power cord in
the storage case. Insert the power jack into the Tech 2 DLC cable (Figure III-5) or into the bottom of the
Tech 2 next to DLC cable connector (Figure III-6).
5. Turn on power by pressing the PWR button located on the Tech 2 keypad.
6. Tech 2 hardware will be verified automatically by the POST test. (For information on this program, refer
to Section VI - Troubleshooting.)
7. Disconnect the RS-232 loopback adapter, the power supply, and the DLC loopback adapter and return
to the Tech 2 storage case (Figure III-7).
Figure III-2 – Connection of the RS-232
loopback adapter to the RS-232 port
Figure III-3 – Connection of the DLC cable
to the VCI connector
Figure III-4 – Connection of the DLC
loopback adapter to the DLC cable
Figure III-5 – Connection of the power jack
to the DLC cable
Figure III-6 – Connection of the power jack
to the bottom of the Tech 2
Figure III-7 – Disconnection of the RS-232
loopback adapter, DLC loopback adapter,
and the power supply
