SECTION VIIA TECH 2 MAIN MENU & LIVE PLOT
2005 Tech 2 User’s Guide VII - 3
Diagnostics
Selecting Diagnostics from the Tech 2 Main Menu and identifying the vehicle as shown below gives you
access to four major systems: Powertrain, Body, Chassis, and Diagnostic Circuit Check (Figure VIIA-2).
Figure VIIA-2
System Selection Menu
F0: DIAGNOSTICS
Vehicle Identification:
Select Model Year
1991-2003
Select Vehicle Type
Passenger Car
LD Trk, MPV, Incomplete
Medium Duty Truck, Saturn
Select System
F0: F1: F2: F3:
Powertrain Body Chassis Diagnostic Circuit Check
To Next Page
