SECTION VIIA TECH 2 MAIN MENU & LIVE PLOT
2005 Tech 2 User’s Guide VII - 4
Service Programming System
Selecting Service Programming System from the Tech 2 Main Menu leads to selections shown below.
Refer also to Section VIIC.
F1: SERVICE PROGRAMMING
(for remote programming only)
Request Info.
Continue (soft key) with Instructions
Vehicle Identification:
Salesmake(s)
Model Year(s)
Vehicle Type(s)
Model (body, style)
Continue (soft key) with Instructions
VIN Verification (Y/N)
Procedural Instructions Screen
View Captured Data
Selecting View Captured Data from the Tech 2 Main Menu results in the selections shown below.
F2: VIEW CAPTURED DATA
Capture Info Snapshot
Select Items, Plot, Select Frame, Auto Reverse, Stop, Auto Forward
F0: DTC Information First Frame, Trigger Frame, Last Frame, Units, Previous Frame,
F1: Freeze Frame / Failure Records Next Frame DTC, Previous DTC-Chg, Next DTC-Chg
Live Plot - Change Min/Max, Zoom In-Out
To Next Page
